The SIPLUS SCALANCE X-100 media converters also feature conformal coated PCBs for use in harsh environments. Integration of an optical path into a redundant ring is also possible, as well as installation of the SCALANCE X-100 media converters into a standby link.
Single, remote terminal units or network segments can be linked via the optical path of the SCALANCE X-100 media converters. They are designed for installation in the control cabinet. The unmanaged media converters of the SCALANCE X-100 product line permit low-cost conversion of electrical signals into optical signals in Industrial Ethernet line, star and ring topologies. Error signaling contact with easy adjustment using the SET button.Diagnostics on the device by means of LEDs (power, link status, data communication).Rugged node connections with industry-standard RJ45 plug-in connectors with retaining collar that offers additional strain and bending strain relief thanks to latching on the enclosure.Rugged metal enclosure for space-saving cubicle mounting on standard rails, SIMATIC S7-300 DIN rails, or for wall mounting.
Electrical or optical connection to nodes or networks according to port characteristics of the devices.
The unmanaged Industrial Ethernet media converters of the SCALANCE X-100 product line are ideally suited to converting electrical signals into optical signals in Industrial Ethernet networks at data transfer rates of 10/100 Mbps in line and star topologies.
